Description

Specifications

Ranges of measurement: 0 to ±25D Minimum: 0.125D graduation up to ±5D 0.25D graduations over ±5D to±25D

Cylinder Axis Range: 0 ~180°step 1°

Prismatic Power Range: Prism diopter of Pattern A: at 1△ interval in the range of 0~5△Prism diopter of Pattern B: at 1△ interval in the range of 0~20△

Prism base angle :at 50 intervals in the range of 0 ~180 degree

Eyepiece Adjustment: ±5D Measurand

Lens Diameter: φ16 ~φ80mm

Dimensions: 275mm(high)×130mm (wids) ×455mm(deep)

Weight: 5.6kg

Lamp: 220V15W 110V15W
