Specifications
- Sphere: 0 to +25 D, steps 0.01 / 0.06 / 0.12 / 0.25 D
- Cylinder: 0 to +10 D, steps 0.01 / 0.06 / 0.12 / 0.25 D
- Axis: 0–180° (1° steps)
- Addition: 0 to +10 D, steps 0.01 / 0.06 / 0.12 / 0.25 D
- Prism: 0.01 Δ steps
- Cylinder notation: +, +/−; prism: X-Y, P-B
- Contact lenses: soft and hard
Progressive lenses
Recognises automatically whether a lens is single vision or progressive. For single-vision lenses the optical centre is found quickly; for progressive lenses the addition is measured accurately.
UV and blue light
Measures the UV transmission of lenses (coated lenses, sunglasses, crystal glass) from 0% to 100% in steps of 1% or 5%.
Marking
Marking pins with red and white ink.
