The Prima Mu OPH is a versatile ophthalmic surgical microscope built for both surgical and clinical use, combining an apochromatic optical system with a bright, long-life LED light source and motorized movement. Its RedReflex illumination makes it easy to spot ruptured vessels, arteries or optic disc damage against an illuminated retina, and MaxLite anti-reflective, anti-scratch coatings keep the optics artifact-free and durable. A wide range of ProLine camera adapters lets you connect a digital SLR or video camera for documentation and teaching.
Specifications
- Mounting: heavyweight H-shape base on lockable castor wheels, swivel arm on a pillar
- Suspension arm: 980 mm
- Magnichanger: 3-step, 0.6x / 1.0x / 1.6x
- Viewing bodies: binocular tubes 45°, IPD range 55-75 mm, f=170 mm
- Objective: f=200 mm
- Eyepieces: WF adjustable 10x/FN 18 mm with eye guards
- Illumination: integrated 27W LED, up to 50,000 hours lifetime, 75,000 Lux
- Power supply: AC 115-240V, 50/60Hz
- Filters: yellow and green with filter holder
- Vertical arm movement: 600 mm
- Includes: objective CMO 200 mm, foot control for height adjustment, securing tools, sterilizable knob covers, nylon dust cover
